Operating Temperature Range-40° to +70°C (standard) -55° to +85°C (extended) Non-condensing environment
-
Maximum Scan Rate1000 Hz
-
Analog Inputs16 single-ended or 8 differential (individually configured). Two analog inputs can measure 4 to 20 mA or 0 to 20 mA natively. Four analog inputs can provide pulse/digital I/O functions.
-
Voltage Excitation Terminals4 (VX1 to VX4)
-
Maximum Source/Sink Current±40 mA (voltage excitation) 50 mA (switched regulated)
-
Communications PortsEthernet USB Micro B CS I/O RS-232 RS-422 CPI RS-485
