参数技术指标/Technique
-
额定容量0.1,0.2,1,2,3,5,10,15,20,25,30t
-
输出灵敏度2.0±1%mV/V(0.1,0.2kN) 3.0±1%mV/V(1~30kN)
-
零点输出±1% F.S.
-
非线性0.03%F.S.
-
滞后0.03%F.S.
-
重复性0.03%F.S.
-
蠕变（30min）0.03%F.S.
-
温度灵敏度漂移0.02%F.S./10℃
-
零点温度漂移0.02%F.S./10℃
-
输入电阻780±10Ω
-
输出电阻700±5Ω
-
绝缘电阻≥5000MΩ/100VDC
-
激励电压5~15V
-
大激励电压20V
-
温度补偿范围-10~40℃
-
工作温度范围-10~70℃
-
安全超载150%F.S.
-
极限超载200%F.S.
-
电缆线尺寸φ5×6000mm
